MIB database management (backup and
restore)
204
WebEML User Manual
Figure 105 Backup MIB Management database dialog box
10. Navigate to the directory to save the MIB Management Database.
11. Enter the file name of the MIB Management Database backup file in the File
Name field.
12. Click Save.
Backup confirmation window opens.
13. Click Yes.
MIB Management window opens.
14. Click OK.
To restore the MIB management database
1. Select Protection Schemes tab.
2. Verify that no forced protection switches are active.
Note: Database backup file name supports a thirty-six character free-form string name. To
aid in tracking database backup files, it is recommended to use the NE Name and Date in
the backup file name (ex. V020200_Chicago-1120_2010-04-30.bar) or follow local
practices and procedures to construct backup file names.
Release 7.0.0 3DB 19286 ACAA Issue 01
