WebEML User Manual MIB database management (backup and
restore)
207
2. Click Yes.
MIB Management window opens.
3. Click OK.
4. Close the WebEML window.
The NE will activate the restored MIB Management database. There may be a
delay of 60 to 90 seconds before the Activate process begins. The NE will
automatically restart. A loss of communication with the NE will occur. Do not
attempt any WebEML activities until the NE has completed restarting. Once the
craft realigns with the NE, it is OK to log in to the system. Restarting the NE can
take up to 10 minutes to complete.
5. Wait until the NE realigns with the craft, then log in to the system using the craft
terminal.
6. Communication with the NE has been established and the NE has been restored
as expected?
a. If yes, go to step 8.
b. If no, go to step 7
7. Has a minimum of 15 minutes elapsed since the database activation was
started?
a. If yes, contact next level of support.
b. If no, wait at least 15 minutes to allow the NE time to reboot and realign with
the craft. Once the NE realigns with the craft, go to step 5.
8. Is the NE configured with a spare Core card?
a. If yes, go to step 9.
b. If no, go to step 10.
Note: Because MIB database restore affects local IP address provisioning, it will be
necessary to connect to the MSS shelf using the same IP address provisioned at the time
of the database backup. If no IP address provisioning was performed prior to MIB database
restore it will be necessary to connect to the MSS shelf using the default IP address
(10.0.1.2) and the main TMN port.
Release 7.0.0 3DB 19286 ACAA Issue 01
