WebEML User Manual Administer Ethernet Ring Protection (ERP)

303

1. Provision the Hold Off timer for any Ethernet ports in the ERP Instance. For

detailed steps, see Provision Ethernet ports.

To force a Ring protection switch

1. To force a ring protection switch, perform one of the following:

− Disable the SFP port for an optical Ethernet interface

− Disable an L1 LAG

Release 7.0.0 3DB 19286 ACAA Issue 01
