Administer Ethernet Ring Protection (ERP)
302
WebEML User Manual
Figure 165 Delete VLAN IDs from ERP Instance
To add a VLAN to an ERP Instance
1. Add VLAN Ethernet flows to ERP Instance using the following procedure:
See Figure 164 for the following steps:
a. Select ERP instance to add VLAN flows.
b. Enter VLAN IDs in Add VLANS text field.
c. Click >>.
d. VLAN IDs are added to the VLAN ID table.
e. Click Apply.
2. Add Ethernet Flow to VLAN Configuration. For detailed steps to add VLAN
Ethernet Flow, see Administer VLAN configuration.
To delete VLAN IDs from an ERP Instance
1. Delete or modify Ethernet Flow from VLAN Configuration. For detailed steps to
delete or modify VLAN Ethernet Flow, see Administer VLAN configuration.
2. Delete VLAN Ethernet flows from ERP Instance using the following procedure:
See Figure 165 for the following steps:
a. Select ERP instance to delete VLAN flows.
b. Select VLAN IDs in VLAN ID table.
c. Click Delete.
d. VLAN IDs are removed from the VLAN ID table.
e. Click Apply.
To provision the Hold off timer
Release 7.0.0 3DB 19286 ACAA Issue 01
