WebEML User Manual Administer Ethernet Ring Protection (ERP)
301
e. Click Apply.
Figure 164 Add VLAN IDs to ERP Instance
2. Add VLAN IDs to Ethernet Ring cross-connections. For detailed steps to add
PDH, Radio, Eth, and Pass-Through to Ring cross-connections, see Provision
cross connections.
To delete PDH, Radio, ETH, OR Pass-Through VLAN IDs from an ERP Instance
1. Delete VLAN IDs from Ethernet Ring cross-connections. For detailed steps to
delete PDH, Radio, Eth, and Pass-Through to Ring cross-connections, see
Deprovision cross connections.
2. Delete PDH, Radio, Eth, and Pass-Through VLAN IDs from ERP Instance using
the following procedure:
See Figure 165 for the following steps:
a. Select ERP instance to delete Radio flows.
b. Select VLAN IDs in VLAN ID table.
c. Click Delete.
d. VLAN IDs are removed from the VLAN ID table.
e. Click Apply.
Release 7.0.0 3DB 19286 ACAA Issue 01
