Administer Ethernet Ring Protection (ERP)
300
WebEML User Manual
2. Modify or Delete Ethernet Flow from VLAN Configuration. For detailed steps to
modify or delete VLAN Ethernet Flow, see Administer VLAN configuration.
3. Delete VLAN IDs from Ethernet Ring cross-connections. For detailed steps to
delete PDH, Radio, Eth, and Pass-Through to Ring cross-connections, see
Deprovision cross connections.
4. From the ERP Instance area, select ERP instance to delete. See Figure 161.
5. Click Delete.
Confirm Operation window opens.
6. Click Yes.
To delete a Ring topology
1. From the Ring Topology area, select Ring Topology to delete. See Figure 161.
2. Click Delete.
Confirm Operation window opens.
3. Click Yes.
To add PDH, Radio, ETH, OR Pass-Through VLAN IDs to an ERP Instance
1. Add PDH, Radio, Eth, and Pass-Through VLAN IDs to ERP Instance using the
following procedure:
See Figure 164 for the following steps:
a. Select ERP instance to add VLAN IDs.
b. Enter VLAN IDs in Add VLANS text field.
c. Click >>.
d. VLAN IDs are added to the VLAN ID table.
Note: Ring topology can be deleted only when the following conditions exist:
If no cross-connections are configured on either ERP Instance associated with the Ring
Topology
No ERP Instances are associated with the ERP Topology.
Release 7.0.0 3DB 19286 ACAA Issue 01
