Administer Ethernet Ring Protection (ERP)
296
WebEML User Manual
• To add a VLAN to an ERP Instance
• To provision the Hold off timer
• To delete VLAN IDs from an ERP Instance
• To provision the Hold off timer
• To force a Ring protection switch
To open the Ethernet Ring Configuration View
1. Select Ethernet Ring Configuration View icon from the main toolbar. See
Figure 160.
Figure 160 Ethernet Ring Configuration View icon
Ethernet Protection Ring Configuration window displays. See Figure 161.
Figure 161 Ethernet Protection Ring Configuration View
Release 7.0.0 3DB 19286 ACAA Issue 01
