WebEML User Manual Administer Ethernet Ring Protection (ERP)
297
To enable an ERP Instance
1. From the ERP Instance area, select ERP instance to enable. See Figure 161.
2. Select ERP Enabled check box (checked).
3. Click Apply.
To disable an ERP Instance
1. From the ERP Instance area, select ERP instance to disable. See Figure 161.
2. Select ERP Enabled check box (unchecked).
3. Click Apply.
To modify ERP Instance parameters with ERP Instance enabled
1. From the ERP Instance area, select ERP instance to modify. See Figure 161.
2. Modify one or more of the following ERP Instance parameters using the
following procedure:
See Figure 162 for the following steps:
a. Modify ERP Label in the Label field, if applicable.
b. Is Ring Node RPL Owner?
a. If yes, go to step c.
b. If no, go to step d.
c. From the Wait-to Restore Time drop-down menu, select 1 to 12 minutes, if
applicable.
d. In the Guard Timer field, enter Guard Timer duration; 10 to 2000 ms, if
applicable.
e. Click Apply.
Release 7.0.0 3DB 19286 ACAA Issue 01
