WebEML User Manual Administer L1/L2 radio and L2 Ethernet LAG
ports
321
Figure 175 Remove Ethernet ports from LAG port
i. From the Configured LAGs pane, select LAG to remove ports.
ii. If last L1/L2 Radio LAG port and PPP RF is enabled, then from the PPP RF
pane, select the Enabled check box (unchecked).
iii. If last L1 Radio LAG port and SSM is enabled, then from the SSM pane,
select the Enabled check box (unchecked).
iv. If last L1 Radio LAG port and PTB is enabled, then from the PTB pane,
select the Enabled check box (unchecked).
v. From the Added Ports pane, select the Port to remove from LAG.
vi. Click <.
vii. Repeat this procedure to remove additional ports from the LAG.
viii. Click Apply.
22909
viii
v
i
vi
Note: In Provider Bridge mode, a port removed from an L2 Ethernet LAG will be managed
as an NNI port.
