Administer L1/L2 radio and L2 Ethernet LAG
ports
322
WebEML User Manual
To enable a LAG port
1. Using the LAG Configuration Tool Settings tab, enable LAG port using the
following procedure: See Figure 176.
Figure 176 Enable/disable LAG port
i. From the Configured LAGs pane, select the LAG to enable.
ii. From the LAG Information pane, select the Enabled check box (checked).
iii. Click Apply.
2. Disable LAG port
Using the LAG Configuration Tool Settings tab, disable LAG port using the
following procedure: See Figure 176.
Release 7.0.0 3DB 19286 ACAA Issue 01
