WebEML User Manual Administer L1/L2 radio and L2 Ethernet LAG
ports
323
i. From the Configured LAGs pane, select LAG to disable.
ii. From the LAG Information pane, select the Enabled check box
(unchecked).
iii. Click Apply.
3. Configure Provider Bridge port type of an L2 Ethernet LAG port
Using the LAG Configuration Tool Settings tab, configure the port type using the
following procedure: See Figure 177.
4. Verify that the LAG port is enabled. To enable it, go to step 1.
i. From the Configured LAGs pane, select the L2 Ethernet LAG.
ii. Select the Provider Bridge tab.
iii. Choose the port type: NNI, UNI (port-based), or UNI (VLAN-based).
Note: To disable a LAG port, all cross-connections, VLANs, and Port segregation,
synchronization reference provisioning must be removed from the LAG port.
If the L2 Ethernet LAG port is configured as UNI (VLAN-Based) in Provider Bridge mode, to
disable a LAG port, Ingress C-VLAN / S-VLAN Mappings must be removed.
Note: The NE must be in Provider Bridge mode.
Release 7.0.0 3DB 19286 ACAA Issue 01
