WebEML User Manual Administer L1/L2 radio and L2 Ethernet LAG
ports
329
Figure 180 Provision hashing level for L2 Ethernet/radio LAG port
i. From the Configured LAGs pane, select LAG to provision hashing level.
ii. From the LAG Information pane, in the Hash drop-down menu, select (L2
or L3).
iii. Click Apply.
To enable SSM support for L1 radio LAG port
1. Using the LAG Configuration Tool Settings tab, enable SSM support using the
following procedure: See Figure 181.
Release 7.0.0 3DB 19286 ACAA Issue 01
