Administer L1/L2 radio and L2 Ethernet LAG
ports
328
WebEML User Manual
v. Click Apply.
3. Disable PPP RF on radio LAG port
Using the LAG Configuration Tool Settings tab, disable PPP RF configuration
using the following procedure: See Figure 179.
i. From the Configured LAGs pane, select LAG to disable PPP RF channel.
ii. From the PPP RF pane, select Enabled check box (unchecked).
iii. Click Apply.
To provision hashing level for L2 Ethernet/radio LAG port
1. Using the LAG Configuration Tool Settings tab, provision Hashing level using
the following procedure: See Figure 180.
Note: OSPF Area must be provisioned prior to provisioning PPP RF channel.
Release 7.0.0 3DB 19286 ACAA Issue 01
