WebEML User Manual Administer L1/L2 radio and L2 Ethernet LAG
ports
327
Figure 179 Enable PPP RF on L1/L2 radio LAG configuration
i. From the Configured LAGs pane, select LAG to enable PPP RF channel.
ii. From the PPP RF pane, select Enabled check box (checked).
iii. Select Routing IP Protocol: (OSPF or None).
iv. If OSPF is selected, then select OSPF Area: (0 to 4).
Note: The PPP RF channel for TMN is managed at LAG level and not at ODU level.
Note: In applications with two parallel LAG groups, the PPP rules are the same as for
Nx(1+0) and Nx(1+1). The PPP RF option must be disabled on all links except one. The
PPP traffic may us the other links for protection, when the enabled link is failed. This
protection may require waiting for the destination MAC address to age out of the forwarding
table before recovering.
Release 7.0.0 3DB 19286 ACAA Issue 01
