Administer L1/L2 radio and L2 Ethernet LAG
ports
326
WebEML User Manual
− Port Segregation
− VLANs
− If L1 radio LAG port, synchronization reference
− If L1 radio LAG port, PPP RF enabled
− If L1 radio LAG port, SSM enabled
2. To disable an L2 Ethernet or L1/L2 Radio LAG port.
3. Remove Ethernet or Radio ports from LAG.
4. From the Configured LAGs pane, select LAG to destroy. See Figure 167.
5. From the Configured LAGs pane, click Destroy.
The Confirm operation window displays.
6. Click Yes.
The L2 Ethernet or L1/L2 Radio LAG port is removed from the Configured LAGs
pane.
To administer PPP RF configuration
1. Select action.
a. To Enable PPP RF on radio LAG port, go to step 2.
b. To Disable PPP RF on radio LAG port, go to step 3.
2. Enable PPP RF on radio LAG port
Using the LAG Configuration Tool Settings tab, enable PPP RF configuration
using the following procedure: See Figure 179.
Note: For a detailed procedure to disable L2 Ethernet or L1/L2 Radio LAG port, see Disable
LAG port, step 2.
Note: For a detailed procedure to remove Ethernet or Radio ports from a LAG port, see To
remove Ethernet or radio ports from a LAG port, step 1.
Release 7.0.0 3DB 19286 ACAA Issue 01
