Provision Ethernet Ring Protection (ERP)
570
WebEML User Manual
5. Provision ERP Instance using the following procedure:
See Figure 383 for the following steps:
a. Enter ERP Label in the New ERP Label field.
b. Enter R-APS VLAN ID in the R-APS VLAN ID field.
c. From the R-APS MEG Level drop-down menu, select R-APS MEG Level for
the ERP Topology.
d. From the R-APS MEG ID East drop-down menu, select ring link east port
ID#.
e. From the R-APS MEG ID West drop-down menu, select ring link west port
ID#.
f. For Ring Node which is RPL Owner, select RPL Owner check box
(checked),
for Ring Node which is not RPL Owner, RPL Owner check box
(unchecked).
RPL Owner selected?
a. If yes, go to step g.
b. If no, go to step h.
g. Select RPL Owner Port, East Port or West Port.
h. Click Create.
Note: R-APS VLAN ID must be provisioned to the same value on all Ethernet Ring Nodes
belonging to the ERP Instance.
Note: R-APS MEG Level must be provisioned to the same value on all Ethernet Ring Nodes
belonging to the ERP Instance.
Release 7.0.0 3DB 19286 ACAA Issue 01
