Configure radio parameters
790
WebEML User Manual
k. To Provision the MPT-HL Synchronization Status Messaging, go to step 34
l. To Provision the MPT-HL Point to Point Protocol settings, go to step 35.
m. To Provision the PKT throughput booster setting, go to step 36.
n. To Administer the MPT-HL Alarm Profile settings, go to step 37.
2. Provision the MPT-HL radio protection type
From the Equipment tab, select the MPT-HL Dir#-Ch1 in the resource tree area.
The selected name will be highlighted in blue. This selection also highlights the
MPT-HL transceiver icon in blue in the resource list area.
3.
From the Protection Type drop-down menu, choose No Protection, 1+1 HSB/
SD, or 1+1 FD. See Figure 597.
4. Click Apply.
Note: Any spare MPT-HL transceiver must be enabled prior to provisioning MPT-HL
transceiver protection scheme.
Note: Before changing the protection type provisioning, you must first apply the No
Protection option to the protection type. For example: If 1+1 HSB is provisioned and 1+1 FD
is needed, first select No Protection and click Apply, then select 1+1 FD and click Apply.
Release 7.0.0 3DB 19286 ACAA Issue 01
