WebEML User Manual Configure radio parameters
793
v. In the Data Help window, double-click on the table row for the desired shifter
value.
vi. When the MPT-HL is connected to the MSS shelf, the Channel #1 TxFreq
(KHz) field is automatically populated. If the MPT-HL is not connected, enter
the TX Radio Frequency within the allowed range.
vii. If the MPT-HL is not connected, enter the Rx Radio Frequency within the
allowed range.
viii. Enter the MPT-HL radio channel User Label, if applicable.
ix. Click Apply.
8. Select an action.
a. To Provision the MPT-HL 1+1 spare radio channel, go to step 13.
b. To Provision the MPT-HL manual transmit power level (RTPC), go to
step 16.
c. To Provision the MPT-HL Automatic Transmit Power Control (ATPC), go to
step 19.
9. Provision the MPT-HL radio for adaptive modulation
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 599.
Note: The Channel #1 Rx Freq (KHz) field displays the Rx Radio Frequency and is the
result of the following calculation: RX Frequency = TX Frequency - Shifter Frequency
Note: In a Protected MPT-HL configuration, the Main and Protect MPT-HL cards use the
same CT screen. The parameters on the Spare (Channel #0) part of the screen are the
same as the Main (Channel #1) part of the screen. Most Channel #0 fields will be
automatically populated to match Channel #1, except the transmit power. The transmit
power must be configured independently.
Release 7.0.0 3DB 19286 ACAA Issue 01
