WebEML User Manual Configure radio parameters
797
b. To Provision the MPT-HL Automatic Transmit Power Control (ATPC), go to
step 19.
15. Provision the MPT-HL manual transmit power level (RTPC)
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 598.
16. Provision the MPT-HL radio channel transmit power level:
i. Choose the TxPower (dBm) level for the lowest modulation scheme in the
range. Power levels for the other modulation schemes will be set
automatically.
ii. Click Apply.
17. Select an action.
a. To Provision the spare MPT-HL RTPC, go to step 18.
b. To Provision the MPT-HL radio protection scheme, go to step 25.
18. Provision the spare MPT-HL RTPC
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 600.
19. Provision the Spare MPT-HL radio channel transmit power level:
i. Choose the TxPower (dBm) level for the lowest modulation scheme in the
range. Power levels for the other modulation schemes will be set
automatically.
ii. Click Apply.
20. Provision the MPT-HL Automatic Transmit Power Control (ATPC)
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 601.
Release 7.0.0 3DB 19286 ACAA Issue 01
