Use the Provisioning Tool
912
WebEML User Manual
v. Enable the J0, if required, by selecting one of the two modes
(SixteenBytesFrame/OneRepeatedByte) in the Expected Receiving Value
field and enter the expected value and in the Sending J0 field select one of
the two modes and enter the value to be transmitted.
vi. Enable, if required, the E1 Node Timing Configuration. The Node Timing is
the timing from the network clock as defined in G.8261. The enabling of the
Node Timing is applied to all E1s of the unit. By enabling the Node Timing
the E1 streams in Rx side are retimed at the output with the network element
clock.
vii. In the Single Tributary Configuration area configure all the E1s to be
mapped/demapped in the STM-1. The E1s are identified by a progressive
number from #1 to #63.
viii. Use the “One Shot” Tributaries Configuration to configure the following
parameters for the E1s:
Service Profile
The available profiles are: TDM2TDM, TDM2Eth
Flow Id: To implement cross-connections between line side and radio
side each E1 tributary must be associated to an identifier. Enter the
Flow identifier value in the relevant field (possible values: 2 to 4080).
The ECID Tx, ECID Rx, Payload Size and TDM Clock Source fields can
be written only if the Service Profile is TDM2Eth.
4. Click on the Next button. The next screen to open depends on the configuration.
To configure the EASv2 unit configuration screen
1. Perform step 2 to configure ports and step 3 to configure protection.
2. In the EASv2 Configuration screen, perform the following for each Ethernet port.
See Figure 683 for electrical ports or Figure 684 for optical ports.
i. Choose the working mode from the drop-down menu:
Transport: to be used as GigaEthernet interface for Ethernet traffic
(Note: for port#5 and port#6 the optional SFP must be installed);
MPT-HC or MPT-HQAM: to be used to connect an MPT-HC to port#1
to port#4; an MPT-HC or MPT-HQAM to port#5 and port#6.
Note: Byte J0 is only read, no Regeneration section Termination is done.
Release 7.0.0 3DB 19286 ACAA Issue 01
