WebEML User Manual Use the Provisioning Tool
927
− 1.024 MHz, electrical levels according to G.703, clause 13 with the following
exception: timing correctly scaled from 2.048 MHz to 1.024 MHz
3. Configure a Wait-to-Restore time as needed.
4. Click on the Next button. The next screen to open depends on the configuration.
To configure the QoS configuration screen
1. The QoS Configuration only refers to queues Q1-Q5.
The QoS Configuration menu has 3 screens. Perform the following:
− For Scheduler Configuration, go to step 2.
− For Queue Size Configuration, go to step 3.
− For QoS Classification, go to step 4.
2. Figure 697 shows the Scheduler Configuration screen, showing the default
configuration.
Release 7.0.0 3DB 19286 ACAA Issue 01
