Administer system settings
180
WebEML User Manual
3. Click on the Close button.
To Provision DHCP server using the Web Server
1. Log In to NE to provision DHCP Server using web browser. For detailed steps
to log in to an NE using a web browser, see Log in to and out of system.
The 9500MPR Web Server displays. Active Alarms is the default web server
window.
2. On Main Menu pane, select DHCP Setting.
The DHCP Setting window displays.
Figure 86 9500 MPR Web Server - DHCP Setting
3. Click on the Refresh button.
4. Determine Current DHCP Status.
5. To change the DHCP provisioning, click on the Enable DHCP/Disable DHCP
button.
To provision Ethernet LOS Criteria
1. From the Ethernet Criteria drop-down menu, select Ethernet LOS Criteria
provisioning: Disabled or Enabled.
2. Click on the Apply button.
Release 7.0.0 3DB 19286 ACAA Issue 01
