Administer synchronization
338
WebEML User Manual
11. From the E1/DS1 Port drop-down menu, select the E1/DS1 Port.
12. Select Secondary Source radio button: Free Run Local Oscillator, E1/DS1
Port, Sync-In Port, Eth Port, STM-1/OC-3 port, or None.
13. Go to step 20.
14. From the Eth Port drop-down menu, select the Eth Port.
15. Select Secondary Source radio button: Free Run Local Oscillator, E1/DS1
Port, Sync-In Port, Eth Port, STM-1/OC-3 port, or None.
16. Go to step 20.
17. From the STM-1/OC-3 Port drop-down menu, select the STM-1OC-3.
18. Select Secondary Source radio button: Free Run Local Oscillator, E1/DS1
Port, Sync-In Port, Eth Port, STM-1/OC-3 port, L1 Radio LAG port, or None.
19. Go to step 20.
20. Which secondary source was selected?
a. If Sync-In Port, go to step 21.
b. If E1/DS1 Port, go to step 23.
c. If Eth Port, go to step 25.
d. If STM-1/OC-3 Port, go to step 27.
e. If Free Run Local Oscillator, go to step 29.
f. If None, go to step 29.
21. In the Sync Ports partition, from the Sync In port drop-down menu, select the
Sync In Port frequency: 1.024 MHz, 2.048 MHz, 5 MHz, or 10 MHz.
Note: If a Sync-In/Out SFP is in use, the Sync Ports area is labeled Sync In/Out
SFPs. The Sync In Port appears as NOT USED. The SFP is displayed as Sync
In Port #5, #6, #7, #8, depending on where the SFP is placed; see Figure 186.
