Configure radio parameters
828
WebEML User Manual
•Rx Freq
ii. From the Option drop-down menu, choose gain configuration identical (Std/
XPIC) to the values provisioned for the horizontal radio channel (step 3ii).
iii. Click Apply.
iv. Provision Vertical radio channel XPIC Configuration Polarization to Vertical.
v. Click Apply.
5. Open the XPIC Configuration tool. See Figure 604.
XPIC Configuration tool displays. See Figure 605.
6. Select Horizontal Radio port and drag to draw line to Vertical RADIO port.
XPIC Association pop-up displays. See Figure 606.
7. Click OK.
8. Click Apply.
9. Click Close.
10. From the MPT Main View, select the 1+0 Horizontal radio channel and verify the
correct radio channel is shown for the Associated Interface Vertical radio
channel. See Figure 607 for an example of a Provisioned Horizontal XPIC radio
channel.
