WebEML User Manual Configure radio parameters
827
g. To Provision the MPT-HLS manual transmit power level (RTPC), go to
step 38.
h. To Provision the spare MPT-HLS RTPC, go to step 41.
i. To Provision the MPT-HLS Automatic Transmit Power Control (ATPC), go
to step 43.
j. To Provision the spare MPT-HLS ATPC, go to step 46.
k. To Provision the MPT-HLS radio protection scheme, go to step 48.
l. To Provision the MPT-HLS link identifier, go to step 54.
m. To Provision the MPT-HLS Synchronization Status Messaging, go to
step 56.
n. To Provision the MPT-HLS Point to Point Protocol settings, go to step 58.
o. To Provision the PKT throughput booster setting, go to step 59.
p. To Administer the MPT-HLS Alarm Profile settings, go to step 61.
q. To Provision the MPT-HLS radio channel encryption, go to step 65.
r. To Administer the RX squelch settings, go to step 68.
2. Provision the MPT-HLS co-channel XPIC configuration
Open the appropriate radio main view click on the Settings tab; see Figure 627.
3. Provision MPT-HLS 1+0 Horizontal XPIC Configuration:
i. Provision 1+0 Horizontal radio channel. See step 29 or 32 for detailed steps
to provision radio channel parameters.
ii. From the Option drop-down menu, choose gain configuration (Std/XPIC.
iii. Click Apply.
iv. Provision Horizontal radio channel XPIC Configuration Polarization to
Horizontal.
v. Click Apply.
4. Provision MPT-HLS 1+0 Vertical XPIC Configuration:
i. Provision 1+0 Vertical radio channel. Provision the Vertical radio channel
using the following radio parameters identical to the values provisioned for
the horizontal radio channel (step 3i).
• Mode
• Reference Channel Spacing
• Modulation
• Shifter
•TX Freq
Release 7.0.0 3DB 19286 ACAA Issue 01
