WebEML User Manual Configure radio parameters
849
For MPT ODU enabled on a Core Ethernet port, P8ETH Ethernet port, EASv2
without PFoE support, or an MSS-1 Core without PFoE support, an external
source of power is required. The external source may be either a Power Injector
card/Box. MPT Power Unit, MPT Extended Power Unit, or direct connection to
an external battery source. In these applications no power scheme provisioning
is required.
3. Which card supports MPT ODU radio port?
a. If MPTACC, MSS-1 port with PFoE support, EASv2 with PFoE support, or
MSS-O with PFoE support, go to step 4.
b. If Core-E, CorEvo, P8ETH, EASv2without PFoE support, or MSS-1 port
without PFoE support, MPT ODU power scheme provisioning is not
required. Go to step 6.
4. Open the appropriate radio main view.
5. Provision MPT ODU power source:
See Figure 635 for the following steps:
i. Select Power Source.
ii. Select the Source # in the resource tree area. The selected name will
highlight in blue. This selection also highlights the Source Number in blue in
the resource list area.
iii. Choose the Settings tab.
iv. From the Source x area, select Power Source 1/2 Type radio button: QMA,
PFoE, or Disabled.
v. Click Apply.
Note: QMA is available with MPTACC only.
Release 7.0.0 3DB 19286 ACAA Issue 01
