WebEML User Manual Configure radio parameters
867
viii. When the radio is connected to the MSS shelf, the Channel #1 TxFreq(KHz)
field is automatically populated. If the radio is not connected, enter the TX
RF Frequency within the allowed range.
ix. The Rx Freq (KHz) displays the Rx RF Frequency.
x. Enter the radio channel User Label, if applicable.
xi. Click Apply.
44. Select an action.
a. To Provision the MPT ODU 1+1 FD spare radio channel, go to step 45
b. To Provision the MPT ODU Manual Transmit Power Level (RTPC), go to
step 48.
c. To Provision the MPT ODU Automatic Transmit Power Control (ATPC), go
to step 53.
45. Provision the MPT ODU 1+1 FD spare radio channel
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 652.
Note: The Channel #1 Rx Freq (KHz) field displays the Rx RF Frequency and is the result
of the following calculation:
RX Frequency = TX Frequency - Shifter Frequency
Note: In a Protected MPT-HC/HQAM configuration, the Main and Protect MPT-HC/HQAM
cards use the same CT screen. The parameters on the Spare (Channel #0) part of the
screen is a mirror image of the Main (Channel #1) part of the screen. Channel #0 fields will
be automatically populated to match Channel #1.
Release 7.0.0 3DB 19286 ACAA Issue 01
