Configure radio parameters
882
WebEML User Manual
To remove XPIC
1. Clear any alarms causing an automatic Tx Mute on the radios; see the
9500 MPR Alarm Clearing User Manual.
2. Remove the XPIC association in the XPIC Configuration screen.
3. Re-provision the radio parameters; see one of the following:
− To provision the MPT-HLC transceiver
− To administer the MPT-HLS transceiver
− To administer the MPT ODU
Note: The modulation scheme must be forced contiguously.For example, if the current
Modulation scheme is 4 QAM, it not possible to force to 64 QAM. The modulation first must
be forced to 16 QAM and then to 64 QAM. Also, if the current modulation is 64 QAM, to pass
to 4 QAM it first must be forced to 16 QAM and then to 4 QAM.
Caution: If an XPIC association is removed while an automatic Tx Mute is active,
the Tx Mute may remain on the system after the removal.
Release 7.0.0 3DB 19286 ACAA Issue 01
