WebEML User Manual Administer L1/L2 radio and L2 Ethernet LAG
ports
313
7. From the LAG Information pane Hash drop-down menu, select hashing level:
(L2 or L3).
8. From the LAG Information pane, select Enabled check box (checked).
9. Click Apply.
10. Verify L2 Ethernet LAG port provisioning.
To create an L1/L2 Radio or L2 Ethernet LAG port
1. Using the LAG Configuration Tool Settings tab, in the configured LAGs pane,
click Create. See Figure 167.
The LAG Creation window displays. See Figure 168.
Note: For a detailed procedure to provision VLAN Configuration, see Administer VLAN
configuration, step 5.
Caution: Adding the first radio port, which is carrying traffic, to a L1 Radio LAG port has an
impact to traffic.
Note: When adding the first radio (Lowest Index Port) to L1 Radio LAG, the following port
add restrictions do not apply. For this case, the following parameters will be reassigned to
the LAG port.
L2 Radio LAG is not available if a CorEvo card is in use.
Release 7.0.0 3DB 19286 ACAA Issue 01
