WebEML User Manual Equipment functions

949

Equipment functions

• Core Facing PDH/SDH Tributary Loopback

• Digital Core Facing Loopback

• IF Cable loopback

• Line Facing PDH/SDH Tributary Loopback

• OAM Remote Loopback

• Open and run performance monitoring

• Perform protection switching

• Perform radio power measurements

• Radio Facing Circuit Loopback

• RF Core Facing Loopback

• Administer SDH LAG

• Upgrade and downgrade protection

• Upgrade and downgrade radio profile

• Upgrade MPT-HL to MPT-HL L1 LAG port

• Upgrade MPT ODU to MPT ODU L1 LAG port

• Perform Tx Diversity Antenna operations

Note: Performance monitoring on affected equipment should be disabled before

making configuration changes.
