Administer L1/L2 radio and L2 Ethernet LAG
ports
310
WebEML User Manual
7. Click Apply.
8. From the LAG Information pane, select the Enabled check box (checked).
9. Click Apply.
10. Provision SSM support.
11. Provision packet throughput booster (PTB) if available.
12. Click Apply.
13. Verify L1 Radio LAG port provisioning.
To provision an L2 radio LAG port (not available with a CorEvo card)
1. Using the craft terminal, verify all radio ports, to be members of the L2 Radio
LAG port, are provisioned correctly. Correct any radio port provisioning that
does not correspond to the desired radio performance characteristics. Verify the
following parameters:
− Tx and Rx Frequency
− Shifter
− Synchronization SSM enabled/disabled
Note: For a detailed procedure to provision PPP RF Configuration, see To administer PPP
RF configuration.
Note: For a detailed procedure to provision SSM support, see To enable SSM support for
L1 radio LAG port and To disable SSM support for L1 radio LAG port.
Note: For a detailed procedure to provision PTB, see To enable PTB for L1 radio LAG port
and To disable PTB for L1 radio LAG port.
Release 7.0.0 3DB 19286 ACAA Issue 01
