Use the Provisioning Tool
890
WebEML User Manual
The following buttons appear on every screen:
• Restore: allows to restore in the screen the initial data without any change
• Prev: the procedure goes back to the previous screen (the changed data may
be lost after the Warning message)
• Next: the procedure goes on to the next screen (some checks and data storage
is done)
• Cancel: the procedure goes back to the opening screen
• Help: click on this button to open the help on line.
61.3 Procedures
This section provides the following procedures:
• To open the Provisioning tool
• To configure the MPT Access peripheral configuration screen
• To configure the MPT Configuration screen
• To configure the P32E1DS1 unit configuration screen for the ANSI market
• To configure the P32E1DS1 unit configuration screen for the ETSI market
• To configure the SDH unit configuration screen (ETSI market only)
• To configure the EASv2 unit configuration screen
• To configure the LAG configuration screen
• To configure the XPIC configuration screen
• To configure the Synchronization configuration screen
• To configure the QoS configuration screen
• To configure the Bridge configuration screen
• To configure the Port VLAN configuration screen
Warning: The Provisioning Tool does not support the CorEvo, MSS-O, MSS-1, P8ETH unit,
P2E3DS3, or AUX unit.
In the ANSI market the MP-HL and SDHACC are also not supported.
In the ETSI market, the MOD300 and ODU300 are supported but not documented. For
information, see the documentation from R60.0.0 or an earlier release.
These units must be configured with WebEML.
To configure an MSS-4 or MSS-8 extract the AUX units, if any.
Release 7.0.0 3DB 19286 ACAA Issue 01
