www.ti.com
General-Purpose Input/Output (GPIO)
111
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
System Control and Interrupts
Table 1-53. GPIO Port B MUX 2 (GPBMUX2) Register Field Descriptions (continued)
Bit Field Value Description
21:20 GPIO58 Configure this pin as:
00 GPIO 58 - general purpose I/O 58 (default)
01 MCLKRA - McBSP-A receive clock (I/O)
10 or
11
XD21 - External interface data line 21 (I/O)
19:18 GPIO57 Configure this pin as:
00 GPIO 57 - general purpose I/O 57 (default)
01 SPISTEA - SPI-A slave transmit enable (I/O)
10 or
11
XD22 - External interface data line 22 (I/O)
17:16 GPIO56 Configure this pin as:
00 GPIO 56 - general purpose I/O 56 (default)
01 SPICLKA - SPI-A clock input/output (I/O)
10 or
11
XD23 - External interface data line 23 (I/O)
15:14 GPIO55 Configure this pin as:
00 GPIO 55 - general purpose I/O 55 (default)
01 SPISOMIA - SPI-A slave out, master in (I/O)
10 or
11
XD24 - External interface data line 24 (I/O)
13:12 GPIO54 Configure this pin as:
00 GPIO 54 - general purpose I/O 54 (default)
01 SPISIMOA - SPI slave in, master out (I/O)
10 or
11
XD25 - External interface data line 25 (I/O)
11:10 GPIO53 Configure this pin as:
00 GPIO 53 - general purpose I/O 53 (default)
01 EQEP1I - Enhanced QEP1 index (I/O)
10 or
11
XD26 - External interface data line 26 (I/O)
9:8 GPIO52 Configure this pin as:
00 GPIO 52 - general purpose I/O 52 (default)
01 EQEP1S - Enhanced QEP1 strobe (I/O)
10 or
11
XD27External interface data line 27 (I/O)
7:6 GPIO51 Configure this pin as:
00 GPIO 51 - general purpose I/O 51 (default)
01 EQEP1B - Enhanced QEP1 input B (I)
10 or
11
XD28 - External interface data line 28 (I/O)
5:4 GPIO50 Configure this pin as:
00 GPIO 50 - general purpose I/O 50 (default)
01 EQEP1A - Enhanced QEP1 input A (I)
10 or
11
XD29 - External interface data line 29 (I/O)
3:2 GPIO49 Configure this pin as:
00 GPIO 49 - general purpose I/O 49 (default)
01 ECAP6 - Enhanced Capture input/output 6 (I/O)
10 or
11
XD30 - External interface data line 30 (I/O)
