HRPWM Registers
www.ti.com
346
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
High-Resolution Pulse Width Modulator (HRPWM)
4.3 HRPWM Registers
4.3.1 Register Summary
A summary of the registers required for the HRPWM is shown in Table 4-8.
Table 4-8. Register Descriptions
Name Offset Size(x16) Description
Time Base Registers
TBCTL 0x0000 1/0 Time Base Control Register
TBSTS 0x0001 1/0 Time Base Status Register
TBPHSHR 0x0002 1/0 Time Base Phase High Resolution Register
TBPHS 0x0003 1/0 Time Base Phase Register
TBCNT 0x0004 1/0 Time Base Counter Register
TBPRD 0x0005 1/1 Time Base Period Register Set
Reserved 0x0006 1/0
Compare Registers
CMPCTL 0x0007 1/0 Counter Compare Control Register
CMPAHR 0x0008 1/1 Counter Compare A High Resolution Register Set
CMPA 0x0009 1/1 Counter Compare A Register Set
CMPB 0x000A 1/1 Counter Compare B Register Set
HRPWM Registers
HRCNFG 0x0020 1/0 HRPWM Configuration Register
