Enhanced Quadrature Encoder Pulse (eQEP)
6.10.2.23 QCTMRLAT Register (Offset = 1Fh) [reset = 0h]
QCTMRLAT is shown in Figure 6-43 and described in Table 6-28.
Return to the Summary Table.
QEP Capture Latch
Figure 6-43. QCTMRLAT Register
15 14 13 12 11 10 9 8
QCTMRLAT
R-0h
7 6 5 4 3 2 1 0
QCTMRLAT
R-0h
Table 6-28. QCTMRLAT Register Field Descriptions
Bit Field Type Reset Description
15-0 QCTMRLAT R 0h
The eQEP capture timer value can be latched into this register on
two events viz., unit timeout event, reading the eQEP position
counter.
Reset type: SYSRSn
