www.ti.com
Message Mailbox
783
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Controller Area Network (CAN)
Table 13-2. eCAN-A Mailbox RAM Layout
Mailbox MSGID
MSGIDL-MSGIDH
MSGCTRL
MSGCTRL-Rsvd
CANMDL
CANMDL_L- CANMDL_H
CANMDH
CANMDH_L- CANMDH_H
0 6100-6101h 6102-6103h 6104-6105h 6106-6107h
1 6108-6109h 610A-610Bh 610C-610Dh 610E-610Fh
2 6110 - 6111h 6112-6113h 6114-6115h 6116-6117h
3 6118-6119h 611A-611Bh 611C-611Dh 611E-611Fh
4 6120-6121h 6122-6123h 6124-6125h 6126-6127h
5 6128-6129h 612A-612Bh 612C-612Dh 612E-612Fh
6 6130-6131h 6132-6133h 6134-6135h 6136-6137h
7 6138-6139h 613A-613Bh 613C-613Dh 613E-613Fh
8 6140-6141h 6142-6143h 6144-6145h 6146-6147h
9 6148-6149h 614A-614Bh 614C-614Dh 614E-614Fh
10 6150-6151h 6152-6153h 6154-6155h 6156-6157h
11 6158-6159h 615A-615Bh 615C-615Dh 615E-615Fh
12 6160-6161h 6162-6163h 6164-6165h 6166-6167h
13 6168-6169h 616A-616Bh 616C-616Dh 616E-616Fh
14 6170-6171h 6172-6173h 6174-6175h 6176-6177h
15 6178-6179h 617A-617Bh 617C-617Dh 617E-617Fh
16 6180-6181h 6182-6183h 6184-6185h 6186-6187h
17 6188-6189h 618A-618Bh 618C-618Dh 618E-618Fh
18 6190-6191h 6192-6193h 6194-6195h 6196-6197h
19 6198-6199h 619A-619Bh 619C-619Dh 619E-619Fh
20 61A0-61A1h 61A2-61A3h 61A4-61A5h 61A6-61A7h
21 61A8-61A9h 61AA-61ABh 61AC-61ADh 61AE-61AFh
22 61B0-61B1h 61B2-61B3h 61B4-61B5h 61B6-61B7h
23 61B8-61B9h 61BA-61BBh 61BC-61BDh 61BE-61BFh
24 61C0-61C1h 61C2-61C3h 61C4-61C5h 61C6-61C7h
25 61C8-61C9h 61CA-61CBh 61CC-61CDh 61CE-61CFh
26 61D0-61D1h 61D2-61D3h 61D4-61D5h 61D6-61D7h
27 61D8-61D9h 61DA-61DBh 61DC-61DDh 61DE-61DFh
28 61E0-61E1h 61E2-61E3h 61E4-61E5h 61E6-61E7h
29 61E8-61E9h 61EA-61EBh 61EC-61EDh 61EE-61EFh
30 61F0-61F1h 61F2-61F3h 61F4-61F5h 61F6-61F7h
31 61F8-61F9h 61FA-61FBh 61FC-61FDh 61FE-61FFh
