Enhanced Pulse Width Modulator (ePWM) Module
3.4.7 Event-Trigger Submodule Registers
Figure 3-84 through Figure 3-88 and Table 3-44 through Table 3-48 provide the definitions for the event-
trigger submodule registers.
Figure 3-84. Event-Trigger Selection Register (ETSEL)
15 14 12 11 10 8
SOCBEN SOCBSEL SOCAEN SOCASEL
R/W-0 R/W-0 R/W-0 R/W-0
7 4 3 2 0
Reserved INTEN INTSEL
R-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 3-44. Event-Trigger Selection Register (ETSEL) Field Descriptions
Bits Name Value Description
15 SOCBEN Enable the ADC Start of Conversion B (EPWMxSOCB) Pulse
0 Disable EPWMxSOCB.
1 Enable EPWMxSOCB pulse.
14-12 SOCBSEL EPWMxSOCB Selection Options
These bits determine when a EPWMxSOCB pulse will be generated.
000 Reserved
001 Enable event time-base counter equal to zero. (TBCTR = 0x0000)
010 Enable event time-base counter equal to period (TBCTR = TBPRD)
011 Reserved
100 Enable event time-base counter equal to CMPA when the timer is incrementing.
101 Enable event time-base counter equal to CMPA when the timer is decrementing.
110 Enable event: time-base counter equal to CMPB when the timer is incrementing.
111 Enable event: time-base counter equal to CMPB when the timer is decrementing.
11 SOCAEN Enable the ADC Start of Conversion A (EPWMxSOCA) Pulse
0 Disable EPWMxSOCA.
1 Enable EPWMxSOCA pulse.
10-8 SOCASEL EPWMxSOCA Selection Options
These bits determine when a EPWMxSOCA pulse will be generated.
000 Reserved
001 Enable event time-base counter equal to zero. (TBCTR = 0x0000)
010 Enable event time-base counter equal to period (TBCTR = TBPRD)
011 Reserved
100 Enable event time-base counter equal to CMPA when the timer is incrementing.
101 Enable event time-base counter equal to CMPA when the timer is decrementing.
110 Enable event: time-base counter equal to CMPB when the timer is incrementing.
111 Enable event: time-base counter equal to CMPB when the timer is decrementing.
7-4 Reserved Reserved
3 INTEN Enable ePWM Interrupt (EPWMx_INT) Generation
0 Disable EPWMx_INT generation
1 Enable EPWMx_INT generation
