www.ti.com
Registers
307
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Pulse Width Modulator (ePWM) Module
Figure 3-73. Action-Qualifier Continuous Software Force Register (AQCSFRC)
15 8
Reserved
R-0
7 4 3 2 1 0
Reserved CSFB CSFA
R-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 3-33. Action-qualifier Continuous Software Force Register (AQCSFRC) Field Descriptions
Bits Name Value Description
15-4 Reserved Reserved
3-2 CSFB Continuous Software Force on Output B
In immediate mode, a continuous force takes effect on the next TBCLK edge.
In shadow mode, a continuous force takes effect on the next TBCLK edge after a shadow load into the
active register. To configure shadow mode, use AQSFRC[RLDCSF].
00 Software forcing is disabled and has no effect
01 Forces a continuous low on output B
10 Forces a continuous high on output B
11 Software forcing is disabled and has no effect
1-0 CSFA Continuous Software Force on Output A
In immediate mode, a continuous force takes effect on the next TBCLK edge.
In shadow mode, a continuous force takes effect on the next TBCLK edge after a shadow load into the
active register.
00 Software forcing is disabled and has no effect
01 Forces a continuous low on output A
10 Forces a continuous high on output A
11 Software forcing is disabled and has no effect
