www.ti.com

Peripheral Interrupt Expansion (PIE)

165

SPRUI07–March 2020

Submit Documentation Feedback

System Control and Interrupts

1.6.5.4 External Interrupt 2 Counter (XINT2CTR) (Address 7079h)

For XINT1 and XINT2, there is also a 16-bit counter that is reset to 0x000 whenever an interrupt edge is

detected. These counters can be used to accurately time stamp an occurrence of the interrupt.

Figure 1-94. External Interrupt 2 Counter (XINT2CTR) (Address 7079h)

15 0

INTCTR[15-0]

R-0

LEGEND: R/W = Read/Write; R = Read only; -n = value after reset

Table 1-125. External Interrupt 2 Counter (XINT2CTR) Field Descriptions

Bits Field Description

15-0 INTCTR This is a free running 16-bit up-counter that is clocked at the SYSCLKOUT rate. The counter value is

reset to 0x0000 when a valid interrupt edge is detected and then continues counting until the next valid

interrupt edge is detected. When the interrupt is disabled, the counter stops. The counter is a free-running

counter and wraps around to zero when the max value is reached. The counter is a read only register and

can only be reset to zero by a valid interrupt edge or by reset.

1.6.5.5 External NMI Interrupt Counter (XNMICTR) (Address 707Fh)

Figure 1-95. External NMI Interrupt Counter (XNMICTR) (Address 707Fh)
