eCAP Registers
www.ti.com
378
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Capture (eCAP)
5.8.2.6 CAP4 Register (Offset = Ah) [reset = 0h]
CAP4 is shown in Figure 5-23 and described in Table 5-9.
Return to the Summary Table.
Capture 4 Register
Figure 5-23. CAP4 Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
CAP4
R/W-0h
Table 5-9. CAP4 Register Field Descriptions
Bit Field Type Reset Description
31-0 CAP4 R/W 0h
In CMP mode, this is a time-stamp capture register.
In APWM mode, this is the compare shadow (ACMP) register. You
can update the PWM compare value via this register. CAP4 (ACMP)
shadows CAP2 in this mode.
Reset type: SYSRSn
