Enhanced Capture (eCAP)
5.8 eCAP Registers
This section describes the Enhanced Capture Registers.
5.8.1 eCAP Base Addresses
Table 5-1. ECAP Base Address Table
Bit Field Name
Base Address
Instance Structure
ECap1Regs ECAP_REGS 0x0000_6A00
ECap2Regs ECAP_REGS 0x0000_6A20
ECap3Regs ECAP_REGS 0x0000_6A40
ECap4Regs ECAP_REGS 0x0000_6A60
ECap5Regs ECAP_REGS 0x0000_6A80
ECap6Regs ECAP_REGS 0x0000_6AA0
