11.6.2.4 I2CCLKL Register (Offset = 3h) [reset = 0h]
I2CCLKL is shown in Figure 11-21 and described in Table 11-13.
Return to the Summary Table.
I2C Clock low-time divider
Figure 11-21. I2CCLKL Register
15 14 13 12 11 10 9 8
I2CCLKL
R/W-0h
7 6 5 4 3 2 1 0
I2CCLKL
R/W-0h
Table 11-13. I2CCLKL Register Field Descriptions
Bit Field Type Reset Description
15-0 I2CCLKL R/W 0h
Clock low-time divide-down value.
To produce the low time duration of the master clock, the period of
the module clock is multiplied by (ICCL + d). d is an adjustment
factor based on the prescaler. See the Clock Divider Registers
section of the Introduction for details.
Note: These bits must be set to a non-zero value for proper I2C
clock generation.
Reset type: SYSRSn
