Enhanced Pulse Width Modulator (ePWM) Module
Figure 3-81. Trip-Zone Flag Register (TZFLG)
15 8
Reserved
R-0
7 3 2 1 0
Reserved OST CBC INT
R-0 R-0 R-0 R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 3-41. Trip-Zone Flag Register (TZFLG) Field Descriptions
Bits Name Value Description
15-3 Reserved Reserved
2 OST Latched Status Flag for A One-Shot Trip Event
0 No one-shot trip event has occurred.
1 Indicates a trip event has occurred on a pin selected as a one-shot trip source.
This bit is cleared by writing the appropriate value to the TZCLR register.
1 CBC Latched Status Flag for Cycle-By-Cycle Trip Event
0 No cycle-by-cycle trip event has occurred.
1 Indicates a trip event has occurred on a pin selected as a cycle-by-cycle trip source. The
TZFLG[CBC] bit will remain set until it is manually cleared by the user. If the cycle-by-cycle trip event
is still present when the CBC bit is cleared, then CBC will be immediately set again. The specified
condition on the pins is automatically cleared when the ePWM time-base counter reaches zero
(TBCTR = 0x0000) if the trip condition is no longer present. The condition on the pins is only cleared
when the TBCTR = 0x0000 no matter where in the cycle the CBC flag is cleared.
This bit is cleared by writing the appropriate value to the TZCLR register.
0 INT Latched Trip Interrupt Status Flag
0 Indicates no interrupt has been generated.
1 Indicates an EPWMx_TZINT PIE interrupt was generated because of a trip condition.
No further EPWMx_TZINT PIE interrupts will be generated until this flag is cleared. If the interrupt
flag is cleared when either CBC or OST is set, then another interrupt pulse will be generated.
Clearing all flag bits will prevent further interrupts.
This bit is cleared by writing the appropriate value to the TZCLR register ().
