Enhanced Quadrature Encoder Pulse (eQEP)
6.10.2.8 QUTMR Register (Offset = Eh) [reset = 0h]
QUTMR is shown in Figure 6-28 and described in Table 6-13.
Return to the Summary Table.
QEP Unit Timer
Figure 6-28. QUTMR Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
QUTMR
R/W-0h
Table 6-13. QUTMR Register Field Descriptions
Bit Field Type Reset Description
31-0 QUTMR R/W 0h
QEP Unit Timer
This register acts as time base for unit time event generation. When
this timer value matches the unit time period value a unit time event
is generated.
Reset type: SYSRSn
