eQEP Registers
www.ti.com
422
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Quadrature Encoder Pulse (eQEP)
6.10.2.10 QWDTMR Register (Offset = 12h) [reset = 0h]
QWDTMR is shown in Figure 6-30 and described in Table 6-15.
Return to the Summary Table.
QEP Watchdog Timer
Figure 6-30. QWDTMR Register
15 14 13 12 11 10 9 8
QWDTMR
R/W-0h
7 6 5 4 3 2 1 0
QWDTMR
R/W-0h
Table 6-15. QWDTMR Register Field Descriptions
Bit Field Type Reset Description
15-0 QWDTMR R/W 0h
QEP Watchdog Timer
This register acts as time base for the watchdog to detect motor
stalls. When this timer value matches with the watchdog's period
value a watchdog timeout interrupt is generated. This register is
reset upon edge transition in quadrature-clock indicating the motion.
Reset type: SYSRSn
