Direct Memory Access (DMA) Module
8.9.9 BURST_COUNT Register (Offset = 1023h + [i * E3h]) [reset = 0h]
BURST_COUNT is shown in Figure 8-16 and described in Table 8-12.
Figure 8-16. BURST_COUNT Register
15 14 13 12 11 10 9 8
RESERVED
R-0h
7 6 5 4 3 2 1 0
RESERVED BURSTCOUNT
R-0h R/W-0h
Table 8-12. BURST_COUNT Register Field Descriptions
Bit Field Type Reset Description
15-5 RESERVED R 0h
Reserved
4-0 BURSTCOUNT R/W 0h These bits indicate the current burst counter value:
0h = 0 word left in a burst
1h = 1 word left in a burst
2h = 2 words left in a burst
...
31h = 31 words left in a burst
The above values represent the state of the counter at the HALT
conditions.
