www.ti.com
Peripheral Interrupt Expansion (PIE)
149
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
System Control and Interrupts
Table 1-111. PIE MUXed Peripheral Interrupt Vector Table
INTx.8 INTx.7 INTx.6 INTx.5 INTx.4 INTx.3 INTx.2 INTx.1
INT1.y WAKEINT TINT0 ADCINT XINT2 XINT1 Reserved SEQ2INT SEQ1INT
(LPM/WD) (TIMER 0) (ADC) Ext. int. 2 Ext. int. 1 - (ADC) (ADC)
0xD4E 0xD4C 0xD4A 0xD48 0xD46 0xD44 0xD42 0xD40
INT2.y Reserved Reserved EPWM6_ TZINT EPWM5_TZINT EPWM4_TZINT EPWM3_TZINT EPWM2_TZINT EPWM1_TZINT
- - (ePWM6) (ePWM5) (ePWM4) (ePWM3) (ePWM2) (ePWM1)
0xD5E 0xD5C 0xD5A 0xD58 0xD56 0xD54 0xD52 0xD50
INT3.y Reserved Reserved EPWM6_ INT EPWM5_INT EPWM4_INT EPWM3_INT EPWM2_INT EPWM1_INT
- - (ePWM6) (ePWM5) (ePWM4) (ePWM3) (ePWM2) (ePWM1)
0xD6E 0xD6C 0xD6A 0xD68 0xD66 0xD64 0xD62 0xD60
INT4.y Reserved Reserved ECAP6_INT ECAP5_INT ECAP4_INT ECAP3_INT ECAP2_INT ECAP1_INT
- - (eCAP6) (eCAP5) (eCAP4) (eCAP3) (eCAP2) (eCAP1)
0xD7E 0xD7C 0xD7A 0xD78 0xD76 0xD74 0xD72 0xD70
INT5.y Reserved Reserved Reserved Reserved Reserved Reserved EQEP2_INT EQEP1_INT
- - - - - - (eQEP2) (eQEP1)
0xD8E 0xD8C 0xD8A 0xD88 0xD86 0xD84 0xD82 0xD80
INT6.y Reserved Reserved MXINTA MRINTA MXINTB MRINTB SPITXINTA SPIRXINTA
- - (McBSP-A) (McBSP-A) (McBSP-B) (McBSP-B) (SPI-A) (SPI-A)
0xD9E 0xD9C 0xD9A 0xD98 0xD96 0xD94 0xD92 0xD90
INT7.y Reserved Reserved DINTCH6 DINTCH5 DINTCH4 DINTCH3 DINTCH2 DINTCH1
- - (DMA6) (DMA5) (DMA4) (DMA3) (DMA2) (DMA1)
0xDAE 0xDAC 0xDAA 0xDA8 0xDA6 0xDA4 0xDA2 0xDA0
INT8.y Reserved Reserved SCITXINTC SCIRXINTC Reserved Reserved I2CINT2A I2CINT1A
- - (SCI-C) (SCI-C) - - (I2C-A) (I2C-A)
0xDBE 0xDBC 0xDBA 0xDB8 0xDB6 0xDB4 0xDB2 0xDB0
INT9.y ECAN1INTB ECAN0INTB ECAN1INTA ECAN0INTA SCITXINTB SCIRXINTB SCITXINTA SCIRXINTA
(CAN-B) (CAN-B) (CAN-A) (CAN-A) (SCI-B) (SCI-B) (SCI-A) (SCI-A)
0xDCE 0xDCC 0xDCA 0xDC8 0xDC6 0xDC4 0xDC2 0xDC0
INT10.y Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
- - - - - - - -
0xDDE 0xDDC 0xDDA 0xDD8 0xDD6 0xDD4 0xDD2 0xDD0
INT11.y Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
- - - - - - - -
0xDEE 0xDEC 0xDEA 0xDE8 0xDE6 0xDE4 0xDE2 0xDE0
INT12.y LUF LVF Reserved XINT7 XINT6 XINT5 XINT4 XINT3
(FPU) (FPU) - Ext. Int. 7 Ext. Int. 6 Ext. Int. 5 Ext. Int. 4 Ext. Int. 3
0xDFE 0xDFC 0xDFA 0xDF8 0xDF6 0xDF4 0xDF2 0xDF0
