Peripheral Frames
www.ti.com
130
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
System Control and Interrupts
Table 1-87. Peripheral Frame 1 Registers (continued)
Name Address Range Size (x16) Access Type
(1)
eCAP1 Registers 0x6A00 - 0x6A1F 32
Not EALLOW-protected
eCAP2 Registers 0x6A20 - 0x6A3F 32
eCAP3 Registers 0x6A40 - 0x6A5F 32
eCAP4 Registers 0x6A60 - 0x6A7F 32
eCAP5 Registers 0x6A80 - 0x6A9F 32
eCAP6 Registers 0x6AA0 - 0x6ABF 32
eQEP1 Registers 0x6B00 - 0x6B3F 64
eQEP2 Registers 0x6B40 - 0x6B7F 64
GPIO Control Registers 0x6F80 - 0x6FBF 128 EALLOW-protected
GPIO Data Registers 0x6FC0 - 0x6FDF 32 Not EALLOW-protected
GPIO Interrupt and LPM Select
Registers
0x6FE0 - 0x6FFF 32 EALLOW-protected
(1)
Peripheral Frame 2 only allows 16-bit accesses. All 32-bit accesses are ignored (invalid data can be returned or written).
Table 1-88. Peripheral Frame 2 Registers
Name Address Range Size (x16) Access Type
(1)
System Control Registers 0x7010 - 0x702F 32 EALLOW-protected
SPI-A Registers 0x7040 - 0x704F 16 Not EALLOW-protected
SCI-A Registers 0x7050 - 0x705F 16 Not EALLOW-protected
External Interrupt Registers 0x7070 - 0x707F 32 Not EALLOW-protected
ADC Registers 0x7100 - 0x711F 32 Not EALLOW-protected
SCI-B Registers 0x7750 - 0x775F 16 Not EALLOW-protected
SCI-C Registers 0x7770 - 0x777F 16 Not EALLOW-protected
I2C Registers 0x7900 - 0x793F 64 Not EALLOW-protected
(1)
The ePWM/HRPWM modules can be re-mapped to Peripheral Frame 3 where they can be accessed by the DMA module. To
achieve this, bit 0 (MAPEPWM) of MAPCNF register (address 0x702E) must be set to 1. This register is EALLOW protected.
When this bit is 0, the ePWM/HRPWM modules are mapped to Peripheral Frame 1.
Table 1-89. Peripheral Frame 3 Registers
Name Address Range Size (×16) Access Type
McBSP-A Registers 0x5000 - 0x503F 64 Not EALLOW-protected
McBSP-B Registers 0x5040 - 0x507F 64 Not EALLOW-protected
EPWM1 + HRPWM1 (DMA)
(1)
0x5800 - 0x583F 64
Some registers are EALLOW-protected. Refer to
the device datasheet for details.
EPWM2 + HRPWM2 (DMA) 0x5840 - 0x587F 64
EPWM3 + HRPWM3 (DMA) 0x5880 - 0x58BF 64
EPWM4 + HRPWM4 (DMA) 0x58C0 - 0x58FF 64
EPWM5 + HRPWM5 (DMA) 0x5900 - 0x593F 64
EPWM6 + HRPWM6 (DMA) 0x5940 - 0x597F 64
Figure 1-73. MAPCNF Register (0x702E)
31 1 0
Reserved MAPEPWM
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
