Multichannel Buffered Serial Port (McBSP)
12.8.14 Receive Interrupt Mode
The RINTM bits (see Table 12-35) determine which event generates a receive interrupt request to the
CPU.
The receive interrupt (RINT) informs the CPU of changes to the serial port status. Four options exist for
configuring this interrupt. The options are set by the receive interrupt mode bits, RINTM, in SPCR1.
Table 12-35. Register Bits Used to Set the Receive Interrupt Mode
Register Bit Name Function Type
Reset
Value
SPCR1 5-4 RINTM Receive interrupt mode R/W 00
RINTM = 00 RINT generated when RRDY changes from 0 to 1. Interrupt on
every serial word by tracking the RRDY bit in SPCR1.
Regardless of the value of RINTM, RRDY can be read to
detect the RRDY = 1 condition.
RINTM = 01 RINT generated by an end-of-block or end-of-frame condition
in the receive multichannel selection mode. In the multichannel
selection mode, interrupt after every 16-channel block
boundary has been crossed within a frame and at the end of
the frame. For details, see Section 12.6.8. In any other serial
transfer case, this setting is not applicable and, therefore, no
interrupts are generated.
RINTM = 10 RINT generated by a new receive frame-synchronization pulse.
Interrupt on detection of receive frame-synchronization pulses.
This generates an interrupt even when the receiver is in its
reset state. This is done by synchronizing the incoming frame-
synchronization pulse to the CPU clock and sending it to the
CPU via RINT.
RINTM = 11 RINT generated when RSYNCERR is set. Interrupt on frame-
synchronization error. Regardless of the value of RINTM,
RSYNCERR can be read to detect this condition. For
information on using RSYNCERR, see Section 12.5.3.
12.8.15 Receive Frame-Synchronization Mode
The bits described in Table 12-36 determine the source for receive frame synchronization and the function
of the FSR pin.
12.8.15.1 Receive Frame-Synchronization Modes
Table 12-37 shows how you can select various sources to provide the receive frame-synchronization
signal and the effect on the FSR pin. The polarity of the signal on the FSR pin is determined by the FSRP
bit.
In digital loopback mode (DLB = 1), the transmit frame-synchronization signal is used as the receive
frame-synchronization signal.
Also in the clock stop mode, the internal receive clock signal (MCLKR) and the internal receive frame-
synchronization signal (FSR) are internally connected to their transmit counterparts, CLKX and FSX.
Table 12-36. Register Bits Used to Set the Receive Frame Synchronization Mode
Register Bit Name Function Type
Reset
Value
PCR 10 FSRM Receive frame-synchronization mode R/W 0
FSRM = 0 Receive frame synchronization is supplied by an
external source via the FSR pin.
FSRM = 1 Receive frame synchronization is supplied by
the sample rate generator. FSR is an output pin
reflecting internal FSR, except when GSYNC = 1
in SRGR2.
