System Control and Interrupts
1.4.2 Configuration Overview
The pin function assignments, input qualification, and the external interrupt (XINT1 – XINT7, XNMI)
sources are all controlled by the GPIO configuration control registers. In addition, you can assign pins to
wake the device from the HALT and STANDBY low power modes and enable/disable internal pullup
resistors. Table 1-39 and Table 1-40 list the registers that are used to configure the GPIO pins to match
the system requirements.
(1)
The registers in this table are EALLOW protected. See Section 1.5.2 for more information.
Table 1-39. GPIO Control Registers
Name
(1)
Address Size (x16) Register Description Bit Description
GPACTRL 0x6F80 2 GPIO A Control Register (GPIO0-GPIO31) Figure 1-53
GPAQSEL1 0x6F82 2 GPIO A Qualifier Select 1 Register (GPIO0-GPIO15) Figure 1-55
GPAQSEL2 0x6F84 2 GPIO A Qualifier Select 2 Register (GPIO16-GPIO31) Figure 1-56
GPAMUX1 0x6F86 2 GPIO A MUX 1 Register (GPIO0-GPIO15) Figure 1-47
GPAMUX2 0x6F88 2 GPIO A MUX 2 Register (GPIO16-GPIO31) Figure 1-48
GPADIR 0x6F8A 2 GPIO A Direction Register (GPIO0-GPIO31) Figure 1-59
GPAPUD 0x6F8C 2 GPIO A Pull Up Disable Register (GPIO0-GPIO31) Figure 1-62
GPBCTRL 0x6F90 2 GPIO B Control Register (GPIO32-GPIO63) Figure 1-54
GPBQSEL1 0x6F92 2 GPIO B Qualifier Select 1 Register (GPIO32-GPIO47) Figure 1-57
GPBQSEL2 0x6F94 2 GPIO B Qualifier Select 2 Register (GPIO48 - GPIO63) Figure 1-58
GPBMUX1 0x6F96 2 GPIO B MUX 1 Register (GPIO32-GPIO47) Figure 1-49
GPBMUX2 0x6F98 2 GPIO B MUX 2 Register (GPIO48-GPIO63) Figure 1-50
GPBDIR 0x6F9A 2 GPIO B Direction Register (GPIO32-GPIO63) Figure 1-60
GPBPUD 0x6F9C 2 GPIO B Pull Up Disable Register (GPIO32-GPIO63) Figure 1-63
GPCMUX1 0x6FA6 2 GPIO C MUX 1 Register (GPIO64-GPIO79) Figure 1-51
GPCMUX2 0x6FA8 2 GPIO C MUX 2 Register (GPIO80-GPIO87) Figure 1-52
GPCDIR 0x6FAA 2 GPIO C Direction Register (GPIO64-GPIO87) Figure 1-61
GPCPUD 0x6FAC 2 GPIO C Pull Up Disable Register (GPIO64-GPIO87) Figure 1-64
(1)
The registers in this table are EALLOW protected. See Section 1.5.2 for more information.
Table 1-40. GPIO Interrupt and Low Power Mode Select Registers
Name
(1)
Address
Size
(x16)
Register Description Bit Description
GPIOXINT1SEL 0x6FE0 1 XINT1 Source Select Register (GPIO0-GPIO31) Figure 1-71
GPIOXINT2SEL 0x6FE1 1 XINT2 Source Select Register (GPIO0-GPIO31) Figure 1-71
GPIOXNMISEL 0x6FE2 1 XNMI Source Select Register (GPIO0-GPIO31) Figure 1-71
GPIOXINT3SEL 0x6FE3 1 XINT3 Source Select Register (GPIO32 - GPIO63) Table 1-82
GPIOXINT4SEL 0x6FE4 1 XINT4 Source Select Register (GPIO32 - GPIO63) Table 1-82
GPIOXINT5SEL 0x6FE5 1 XINT5 Source Select Register (GPIO32 - GPIO63) Table 1-82
GPIOXINT6SEL 0x6FE6 1 XINT6 Source Select Register (GPIO32 - GPIO63) Table 1-82
GPIOXINT7SEL 0x6FE7 1 XINT7 Source Select Register (GPIO32 - GPIO63) Table 1-82
GPIOLPMSEL 0x6FE8 1 LPM wakeup Source Select Register (GPIO0-GPIO31) Figure 1-72
